ALL-new NEJE Max Laser Diode Controller System - Laser Control Board for DIY Laser Machine

View detailed information on NEJE.WIKI.

Adopting the all-new sensorless reset technology, there is no need for an additional reset button. Simply adding a 3mm-thick cushioning pad at the collision position can complete the reliable and smooth reset action.

It is recommended to use 24V as the device power supply, which helps to achieve maximum performance. Modules such as E80, E40, A40640, E30, and A40630 all support 24V operation with direct motherboard power supply mode and additional 2-pin power supply, allowing the modules to work in a stable 24V low-current mode. This results in lower power line load and more stable operation.

Supports NEJE's brand-new complex process control software and wireless control operations.

Optimizes numerous GRBL native firmware bugs.

Provides lifetime free firmware upgrade services.

Supports wireless real-time control with Lightburn and LaserGRBL.

Enables wireless or USB content transfer with Lightburn and LaserGRBL software for "REC" offline work. Built-in high-capacity memory allows for offline operation with large file storage, eliminating the need to occupy computer resources or LightBurn, making the process more reliable.

Built-in advanced seamless reset function, no need for additional reset buttons, easy wiring.

2-year free warranty.

The independent A-axis serves as the rotary axis, supporting 4-axis and enabling the development of more automated functions.

Supports complex processes and safety expansions such as M8, M7, and Door.

It can be used for DIY any X, Y, Z, A step motor-driven mechanical structure, with voltage support for 12-24V input.

Older Max series devices, such as NEJE 3 Max, NEJE 2S Max, and the first-generation NEJE Max 4, can all be upgraded with this kit. The installation interface is universal, and the mainboard kit comes with a heat dissipation protective shield, surge protection, and electrostatic discharge protection, among other reliability designs. Please do not remove the heat dissipation protective shield, and when installing, pay attention to the wiring sequence and ensure that the input voltage matches the module voltage.

Packaging List:

Mainboard(With heat dissipation protection) x1,

Matching Cables(Standard Max4 matching cables) x1
