Setting Up Your NEJE with LightBurn and LaserGRBL

Introduction

NEJE 2, 3, 4, and 5 series laser engravers are popular among hobbyists and small businesses for their affordability, compact design, and solid performance on wood, leather, acrylic, and more. These diode laser machines run on GRBL firmware and are fully compatible with two of the most widely used laser control programs: LightBurn (feature-rich and user-friendly) and LaserGRBL (free and lightweight).

How to Set Up NEJE Laser with LightBurn

LightBurn offers advanced features like layering, better image processing, material test grids, and more precise control — making it the top choice for most NEJE users.

1. Create a New Device Open LightBurn and click Devices (or Laser menu → Devices). Choose to manually create a new device.



2. Select the Controller Type: GRBL (Critical!) In the controller selection screen, make sure to pick GRBL.

3. Choose Connection: Select Serial/USB (NEJE machines connect via USB; Bluetooth setups require connection bridge through NEJE software).

4. Enter Your Machine’s Work Area Size Input the correct bed dimensions for your specific NEJE model (e.g., NEJE Max 4 v2 is typically 700×460 mm, so please check your manual or measure).

5. Enable Important Safety & Performance Settings Make sure to enable: Start from Home / Origin (front left)

6. Complete the Wizard Finish the new device creation process.

7. Select Your Machine and COM Port Back in the main window, choose your newly created NEJE device from the dropdown. Select the correct COM port (check Windows Device Manager if unsure — look under “Ports (COM & LPT)” for your NEJE USB connection). Once you choose the right port, your machine will be home automatically.

How to Use LaserGRBL with NEJE Laser Engraver

LaserGRBL is completely free, lightweight, and great for beginners or simple jobs. NEJE machines work plug-and-play in most cases.

· Connect your NEJE via USB.

· Open LaserGRBL and select the correct COM port and baud rate (usually 115200).

· Click Connect.

Safety Tips & Best Practices for NEJE Lasers

• Always supervise jobs — never leave the machine running unattended.
• Use proper laser safety glasses matched to your diode wavelength.
• Work in a well-ventilated area or use exhaust/fume extraction.
• Test settings on scrap material first.
• Keep flammable items far from the work area.
• Update firmware via official NEJE software when available for bug fixes and improvements.

Happy lasering — stay safe and creative!
